| Ask Lasest Price | |
| Brand Name : | Maccsy |
| Certification : | ISO CE |
| Model Number : | LM200 |
| Price : | Negotiable |
| Delivery Time : | Depends on Goods |
| Payment Terms : | T/T, L/C |
| Supply Ability : | 20 Sets / Month |
Photo of the Lathe machine LM200
Technical Parameters
| Max swing over bed | 340mm (133/8") |
| Max swing over cross slide | 210mm (8") |
| Max swing over gap | 470mm (181/2") |
| Distance between centers | 750mm (30") 1000mm (40") |
| Width of bed | 186mm (71/3") |
| Spindle nose | CAMLOCK |
| Spindle bore | 38mm (11/2") |
| Spindle speed (Grades) | 60HZ 60-2000 RPM (9/18 steps) 50HZ 60-2000 RPM (9 steps) 50-1720 RPM (18 steps) |
| Metric threads | 0.25-9mm |
| inch threads | 72-4(3/4)TPI |
| Module threads | 0.25-3.5mm |
| Vertical feeding range | 0.03-0.42 mm |
| Horizontal feeding range | 0.015-0.21mm |
| Main motor power | 1.5KW |
| Net/Gross weight (KG) | 570/670/750 |
